Erw Welded Steel Pipe - Square /Torque Steel Pipe – Rainbow
Erw Welded Steel Pipe - Square /Torque Steel Pipe – Rainbow Detail:
Suqare /torque steel pipe is wildly used in many areas . Like construction, plant building, or solar tracker rotation shaft. We can cut the pipe to certin length according to customer’s requirement.
In order to fulfill different using envirement, hot dip galvanzing coating ,painting are all available. Regarding to some solar plants, clients may request pregalvanized zinc Z275 or magnelis material. Besides surface treatment , punching and cuting work are all avaible. Processing can be done according to per drawing.
| Product Description | ||||||
| Product name | hot dipped galvanized/pregalvanized steel pipe | |||||
| Pipe end | plain end | |||||
| Pipe Length | 3 meters-12 meters | |||||
| Outside daimeter | 1/2 inch-8 inch,50*50mm,80*80mm,100*100mm,120*120mm,150*150mm,170*170mm | |||||
| Processing | punching, cutting | |||||
| Materials | Q195, Q235, Q235B, St37-2, St52, SS400, STK500, ASTM A53, S235JR,S 355JR | |||||
| Standard | API 5CT, GB/T3091, ASTM A53, JIS G 3443,EN10219, | |||||
| Surface | galvanized，pregalvanized，painting | |||||
| Zinc Coating | ISO 1461,55micron,80micron,100 micron | |||||
| Payment term | T/T, L/C | |||||
| Applications | water pipe, low fluid transportation, scaffolding pipe, greenhouse pipes,rotation shaft,support | |||||
| Certificate | ISO9001, SGS, TUV, BV | |||||
| Specifications of Pre Galvanized Steel Pipe | ||||||
| Round Pipe | Rectangular Tube | Square Tube | ||||
| Nominal | Thickness | Size | Thickness | Size | Thickness | |
| IN | MM | MM | MM | MM | MM | MM |
| 1/2″ | 20 | 0.8-2.2 | 20*40 | 0.8-2.0 | 16*16 | 0.8-1.5 |
| 3/4” | 25 | 0.8-2.2 | 25*50 | 0.8-2.0 | 19*19 | 0.8-2.0 |
| —— | 25.4 | 0.8-2.2 | 30*40 | 0.8-2.0 | 20*20 | 0.8-2.0 |
| 1″ | 32 | 0.8-2.2 | 30*50 | 0.8-2.0 | 25*25 | 0.8-2.0 |
| —— | 38 | 1.0-2.2 | 37*57 | 0.8-2.0 | 30*30 | 0.8-2.0 |
| 1-1/4′ | 40 | 1.0-2.2 | 40*60 | 0.8-2.0 | 32*32 | 0.8-2.0 |
| —— | 42 | 1.0-2.3 | 37*77 | 0.8-2.0 | 35*35 | 0.8-2.0 |
| 1-1/2′ | 47 | 1.0-2.3 | 25*75 | 0.9-2.0 | 38*38 | 0.8-2.0 |
| —— | 48 | 1.0-2.3 | 40*80 | 1.0-2.2 | 40*40 | 0.8-2.0 |
| 2″ | 59 | 1.0-2.3 | 50*100 | 1.0-2.2 | 50*50 | 0.8-2.2 |
| —— | 60.3 | 1.0-2.3 | 50*75 | 1.0-2.2 | 60*60 | 1.0-2.2 |
| 2-1/2″ | 75 | 1.0-2.3 | 38*75 | 1.0-2.2 | 75*75 | 1.0-2.2 |
| 3″ | 87 | 1.0-2.3 | 50*150 | 1.3-2.2 | 80*80 | 1.0-2.2 |
| 4″ | 113 | 1.0-2.3 | 100*100 | 1.2-2.2 | ||
Product detail pictures:
